Expert Anti-settling Properties: Specifically formulated to maintain a homogeneous slurry and prevent sedimentation in high-dispersity and low-density systems.
Gas Migration Mitigation: Helps maintain hydrostatic pressure during the critical transition time, significantly reducing the risk of gas channeling.
Marine & Brine Excellence: Optimized for Seawater systems and slurries containing up to 2% CaCl2, making it ideal for offshore and specialized brine cementing.
Rapid Strength Gain: Designed to accelerate WOC (Waiting on Cement) time, achieving ≥14.0 MPa in 24h for normal density slurries.
WHY CHOOSE CG214 FLUID LOSS ADDITIVE
G214 fluid loss additive is a synthetic polymer which is capable of effectively reducing water loss filtering from the slurry to porous formation during cementing process.
Specially designed for lightweight cement slurry system and normal density cement slurry with strong dispersity.
Thickening time decreases with increasing temperature, and the compressive strength of set cement develops fast.
Expert Anti-settling Properties: Specifically formulated to maintain a homogeneous slurry and prevent sedimentation in high-dispersity and low-density systems.
Gas Migration Mitigation: Helps maintain hydrostatic pressure during the critical transition time, significantly reducing the risk of gas channeling.
Marine & Brine Excellence: Optimized for Seawater systems and slurries containing up to 2% CaCl2, making it ideal for offshore and specialized brine cementing.
Rapid Strength Gain: Designed to accelerate WOC (Waiting on Cement) time, achieving ≥14.0 MPa in 24h for normal density slurries.
Used below temperature of 180℃(356℉, BHCT).
Compatible with other additives.
CG214 series contains of L-type liquid, L-A type anti-freezing liquid and S type powder.
Recommended dosage is 2.0-6.0 (BWOC) for liquid products, and 0.6-2.5% (BWOC) for powder product.
PHYSICAL AND CHEMICAL INDICATORS
|
CG214S |
CG214L |
|
Appearance：White or faint yellow powder |
Appearance：Colorless or faint yellow liquid |
|
Bulk Density, g/cm3: 0.80±0.20 |
Density, g/cm3: 1.10±0.05(L), 1.15±0.05(L-A) |
|
Water-Solubility: Soluble |
Water-Solubility: Soluble |
CEMENT SLURRY PERFORMANCE
|
Item |
Test Condition |
Technical Indicator |
||
|
Density of the lightweight cement slurry, g/cm3 |
25℃, Atmospheric Pressure |
1.35±0.01 |
||
|
Density of Dyckerhoff cement slurry with strong dispersity, g/cm3 |
1.90±0.01 |
|||
|
Fluid loss,ml |
Fresh water system |
52℃，6.9MPa |
≤60 |
|
|
Seawater system |
80℃，6.9MPa |
≤100 |
||
|
Slurry containing 2% CaCl2 |
≤80 |
|||
|
Thickening performance |
Initial consistency, Bc |
52℃/28min,35.9MPa |
≤30 |
|
|
40-100 Bc thickening time, min |
≤40 |
|||
|
Free fluid, % |
80℃, Atmospheric Pressure |
≤1.4 |
||
|
24h compressive strength, MPa |
Lightweight cement slurry |
≥5.0 |
||
|
Cement slurry with strong dispersity |
≥14.0 |
|||
PACKING AND STORAGE
The liquid type products should be used within 12 months after production. Packed in 25kg, 200L and 5 US gallon plastic barrels.
The powder type products should be used within 24 months after production. Packed in25kg bag. Once expired, it shall be tested before use.
Customized packages are also available.
Tech Tip: "For deep wells with narrow pressure windows, CG214 ensures that your lightweight slurry remains stable from top to bottom, preventing 'top-of-cement' density variations and ensuring long-term zonal isolation."
